by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — 4 Comments ↓

Hitachi_CP-X417WF_projector_Hitachi DT00841_projector_lampFollow this step-by-step guide to install a new Hitachi CP-X417WF projector lamp.

Start off on the right foot with an authentic lamp

The only replacement Hitachi CP-X417WF projector lamp that will keep your projector working is the Hitachi DT00841 (CPX401) bought from an OEM manufacturer.

While knock-off lamps appear to be a bargain, they will actually end up costing you more money due to their various problems::

When buying look for the seal of approval. Learn to spot copycat lamps posing as authentic lamps.Keep track of projector lamp life.

Find this lamp sold on Amazon by these authorized distributors:

Tracking the projector lamp life

]Watch for these signs that indicated the projector lamp is reaching its end of life:

  • Both the Hitachi CP-X417WF Power and Lamp Indicators are flashing red while the Temp Indicator is turned off.
  • Color tone on the screen may also appear weak or washed out.
  • Picture has poor color quality.

Installing the Hitachi DT00841 (CPX401 projector lamp

Safety steps before installing the Hitachi DT00841 (CPX401):

  • Turn off the Hitachi CP-X417WF projector .
  • Unplug the power cord.
  • Allow the projector to cool for at least 45 minutes. It should be cool to the touch. This projector works using high heat and there is danger you can be burned.
  • NOTE: If the projector is mounted on the ceiling, don’t stand underneath the projector while opening the cover.

Hitachi_CP-X417WF_projector_replace_Hitachi-DT00841_projector_lamp

  • Prepare the new Hitachi CP-X417WF projector lamp. If the projector is mounted on a ceiling, or if the lamp has broken, contact your dealer for assistance.
  • Loosen the screw (marked by arrow) of the lamp cover and then slide the lamp cover to the side to remove it.
  • Loosen the 2 screws (marked by arrow) of the projector lamp, and slowly pick up the lamp by the handles. Be careful not the bang the lamp. The Hitachi DT00841 projector lamp contains mercury and must be recycled properly. Do not throw it in regular garbage.
  • Insert the new lamp, taking care not to touch the actual bulb. Oil in your fingers will cause a dark spot on the lamp when it heats up.
  • Tighten the two screws of the Hitachi DT00841 projector lamp that were loosened to remove the old projector lamp.
  • Slide the lamp cover back in place and firmly fasten the screw of the lamp cover.
  • Turn on the projector and set the lamp timer:

To reset the projector lamp timer:

Hitachi_CP-X417WF_projector_Hitachi-DT00841_projector_lamp_reset_timerNote: Reset the projector lamp time only when you have replaced the lamp so the Hitachi CP-X417WF projector can properly track the lamp life. Otherwise you run the risk of using the lamp beyond its lamp life.

  • Press the MENU button
  • Scroll down to the GO TO ADVANCED MENU option. Press ENTER
  • Scroll down to the OPTION menu in the left column and press ENTER.
  • Scroll down to LAMP TIME. Press ENTER To make a dialogue field appear
  • Scroll up to the RESET option on the dialogue box.
  • The lamp setting will be set to zero.

Hitachi_CP-X417_projector_HReplacing the air filters

Get more hours from your Hitachi DT00841 by keeping your air filters clean to avoid overheating the projector.

  • Pull the filter frame’s knob up while holding the filter cover. The filter frame will come off and the air filter will appear.
  • Take out the old air filter and insert the new air filter.
  • Put the filter frame back.
  • Put the filter unit back into the projector
  • Turn the projector on and reset the filter time using the FILTER TIME item in the EASY MENU.
  • Learn more with Top tips for extending DLP projector lamp life.

Green your projector

Hitachi_DT00841_replacement_projector_lamp_training_video



Recycle your lamp housing by only replacing the Hitachi CP-X417WF lamp. Our training video shows you how to do it.  It’s easy!



Tagged with: , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

ell_1100MP_projector_Dell_310-7522_projector_lampDon’t call service repair. Instead,  follow this guide to replace the DELL 1100MP projector lamp

End of projector lamp warnings

When the lamp light on the Dell 1100 MP turns a solid orange, it’s time to replace the projector lamp. The message “Lamp is approaching the end of its useful life in full power operation. Replacement suggested!” usually appears on screen at the same time.

Don’t wait too long to change the lamp. Pushing it too far can result in the lamp making a loud popping noise before burning out. “Lamp Defective” will show n screen and  remain  until a new projector lamp has been installed.

Go with authentic!

Keep your Dell 1201MP projector needs an OEM Dell 310-7522 projector lamp to keep working at its optimum best. Avoid generics. Knock-off lamps are not calibrated properly so they can damage the sensitive optics in your Dell 1100MP projector. These lamps don’t save you money since they have a much shorter life and present a health hazard and are prone to explosions. Copycat manufacturers also offer no guarantee or refunds. Save yourself hassles and protect your Dell 1100MP projector from being damaged, buy Dell 310-7522 projector authentic projector lamps!

Find this lamp sold on Amazon by these authorized dealers:

Replacing the Dell 310-7522 projector lamp

Before replacing the Dell 310-7522 projector lamp be sure to turn the projector off and disconnect from the AC plug. Let the projector cool down for at least 30 minutes. It should be cool to the touch. Don’t attempt to change the lamp when the projector is still hot as there is a good chance you can get severely burned.

Dell_1100MP_projector_Dell_310-7522_projector_lamp

  • Place the Dell 1100MP on a soft surface and turn in upside down to access the projector lamp cover. Loose the two screws that hold the projector lamp cover in place.
  • Loosen the two screws that secure the projector lamp.
  • Pull the projector lamp up by its metal handle. Pulling too quickly can cause the bulb to shatter. NOTE: Don’t throw the Dell 310-7522 projector lamp into regular garbage! Since it contains mercury, this lamp must be properly recycled.
  • Install the new Dell 310-7522 projector lamp making sure it is properly aligned into the projector.
  • Tighten the two screws that secure the Dell 310-7522 projector lamp.
  • Replace the projector lamp cover and tighten the two screws.
  • You are now ready to reset the lamp timer.

Reset the projector lamp counter

The Dell 1100MP projector tracks the life of the Dell 310-7522 projector lamp and will trigger the warning signals when it’s time to replace. Each time you replace the Dell 310-7522 projector lamp you must reset the lamp timer to zero. Failure to do so can result in you using the projector past the optimum lamp life and causing the projector lamp to explode.

  • To access the Main Menu press the left or right buttons on your projector’s control panel or remote control.
  • Scroll over the the Management Menu. Press ENTER to access.
  • Scroll down to the Lamp Reset icon. Press ENTER.
  • Scroll down to choose YES and reset the projector lamp timer.



Tips for extending Dell 310-7522 projector lamp life:

  • Choose ECO MODE: Select On to use the projector at the lower power level of 150 Watts, which makes the Dell 1100MP projector operate quieter and with lower light that gives more projector lamp life. Select off to operate at the 300 Watts power level.
  • Keep your air filters clean to avoid overheating the projector.
  • Every 24 hours, turn off the projector and let it stand for 1 hour
  • Make sure there is enough airflow around the Dell 1100MP projector projector particularly if it’s been permanently mounted.
  • Learn more with Top tips for extending DLP projector lamp life.

Save money and go green

Video_Changing_Lamp_Dell_1100MPLooking for a green alternative? Try replacing only the projector lamp bulb and re-using the same plastic cage with the Dell 310-7522 projector lamp.

Watch this how to video guide to see more.



Tagged with: , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

Epson_PowerLite_1260_projector_Epson_ELPLP58_projector_lampWhen its time for a new Epson PowerLite 1260 projector lamp, follow this step-by-step guide.

Step 1: Know when to replace

Watch for end life signs. When you see the projector lamp indicator flashing orange, it’s time to change the Epson PowerLite 1260 projector lamp is reaching end of life. You may also see the Replace the lamp message on screens. Other indications are screen gets darker or starts deteriorate altogether. Epson_PowerLite 1260_projector_Epson_ELPLP58_projector_lamp_lamp_warning

In order to maintain projector brightness and image quality, replace with a new Epson LPLP58 (V13H010L58) projector lamp as soon as possible.

The Epson PowerLite 1260 projector lamp can last for close to 4,000 hours when the power consumption is set to NORMAL and up to 5,000 hours if the ECO option is used. You can check the hours left on the ELPLP58 (V13H010L58) projector lamp from the INFO Menu access off the Main Menu. Epson_PowerLite 1260_projector_Epson_ELPLP58_check_projector_lamp_hours

Step 2: Buy authentic

It’s always a good idea to be prepared with a replacement projector lamp so you can do the installation quickly and continue on with your presentation. The Epson PowerLite 1260 uses the Epson ELPLP58 (V13H010L58) projector lamp. Always go with an authentic lamp and avoid the cheaper generic lamp in order to save money. While these knock-off lamps appear to be a bargain, they will actually end up costing you more.

Find this lamp on Amazon sold by these authorized dealers:

Six reasons to avoid generics

Step 3: Installing the new ELPLP58 (V13H010L58) projector lamp

Before replacing the ELPLP58 (V13H010L58) projector lamp follow these important safety rules:

  1. Always unplug the power cord on the Epson PowerLite 1260 projector before replacing the projector lamp.
  2. This projector operates using high temperature. Wait at least 60 minutes before replacing the lamp so you don’t run the risk of getting burned.
  3. Never touch the bare projector lamp bulb as the oil from your fingers will burn black marks onto the projector lamp when it heats up.
  4. Never operate the Epson PowerLite 1260 projector with the projector lamp removed.

Epson_PowerLite 1260_Epson_ELPLP58_remove_projector_lamp_cover

Remove the projector lamp cover screws and place to one side.

Epson_PowerLite 1260_projector_Epson_ELPLP58__remove_projector_lamp_screwsLoosen the two screws holding the Epson ELPLP58 (V13H010L58) projector lamp in place (you can’t remove them).

Epson_PowerLite 1260_projector_Epson_ELPLP58_install_new_projector_lamp

Gently lift out the Epson LPLP58 projector lamp taking care not to bang it against the projector. NOTE: The LPLP58 projector lamp contains mercury and should not be thrown into regular garbage. Recycle this lamp!

Gently insert the new Epson LPLP58 projector lamp. Make sure it fits into the Epson PowerLite 1260 projector properly. (Check that it’s facing the right way.) Tighten the Epson LPLP58 projector lamp.

You can now reset the lamp timer.

Reset the lamp timer

Epson_PowerLite 1260_projector_Epson_ELPLP58_reset_projector_lamp_timer

After you replace the lamp, you need to reset the Epson PowerLite 1260 projector lamp timer using the projector’s menu system.

  • Press the MENU button on the remote control or on the projector’s control panel. You see the main menu.
  • Select the RESET menu. Press ENTER.
  • Scroll down to select RESET LAMP HOURS. Press ENTER.
  • A prompt filed appears asking if you want to reset the lamp timer. Select YES. Press ENTER.
  • Press MENU to exit.

Longer life for the ELPLP58 (V13H010L58) projector lamp

Extend the life of the Epson ELPLP58 (V13H010L58) projector lamp with the following tips:

  • Set the Power Consumption to ECO option.
  • Clean the air filters regularly so the PowerLite 1260 projector doesn’t overheat.
  • Make sure there is enough airflow around the projector.
  • Turn it off when it’s not in use.
  • Learn more: Top tips for extending DLP projector lamp life.
Tagged with: , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

NEC_NP-M230XG_projector_NP15LP_projector_lampUse our guide to help you change the NEC NP-M230XG projector lamp.

Note: These instructions can also be used on the NEC NP-M260XG model.

When to replace the projector lamp

Watch for the following signs that indicates the NEC NP-M230XG projector lamp is reaching end of life and needs to be replaced:

  • message on screen reads LAMP HAS REACHED THE END OF ITS USABLE LIFE. PLEASE REPLACE THE LAMP AND FILTER.
  • the LAMP indicator begins to blink red
  • colour looks off
  • picture is faint or has deteriorated

Be ready with an authentic lamp

In order to keep your NEC NP-M260XG projector working at it’s best, always install an OES NEC NP15LP lamp. Generic projector lamps should be avoided. They’ve been created with substandard toxic materials (including the carcinogenic Krypton-85) making them prone to explosions. Installing them often damages the sensitive electronics in your NEC NP-M260XGprojector and to top it all off they have a shorter life! Save yourself the hassle and buy authentic!

Find this lamp sold on Amazon by these authorized dealers:

Track projector lamp life

NEC_NP-M260XG_check_NECNP15LP_projector_lamp_usageTrack the life of the NEC NP15LP projector lamp from the Usage Time menu.

  • Go to INFO menu
  • Scroll down to USAGE TIME to display the LAMP LIFE REMAINING and LAMP HOURS USED.
  • The progress indicator shows the percentage of remaining bulb life:
  • When the lamp usage reaches 0, the Lamp Life REMAINING starts a count down from 100 hours
  • When the count down reaches 0, the projector will turn off and not turn on.

Changing the NEC NP15LP projector lamp

NOTE: New air filters are shipped with the lamp and it’s recommended you replace them at the same time.

Follow these important safety instructions before installing the new NEC NP15LP projector lamp

  • turn off the NEC NP-M260XG projector.
  • unplug the projector from its power source.
  • unplug the power cable.
  • wait until the projector is cool to the touch to avoid getting burned.

NEC_NP-M260XG_NEC_NP16LP_projector_lamp_remove_lamp_screwLoosen the NEC NP-M260XG projector lamp cover screw.

NEC_NP-M260XG_projector_lamp_NEC_NP16LP_remove_lamp_cover

Push and slide the NEC NP-M260XG projector cover off.

NEC_NP-M230XG_remove_NEC_NP16LP_projector_lamp_screws

Loosen the two screws holding the NEC NP15LP projector lamp in place. (The screws will not come out only loosen.)

NEC_NP-M260XG_remove_NEC_NP16LP_projector_lamp



Remove the projector lamp by holding the indent and pulling up.

NOTE: Your NEC NP15LP lamp should be properly recycled. These lamps contain mercury and can’t be placed into common garbage.

NEC_NP-M260XG_projector_lamp_install_new_NEC_NP16LPInstall a new lamp housing into the NEC NP-M260XG projector, gently pressing the projector lamp housing into the socket. Take care not to touch the actual bulb as your finger prints can leave oil marks that burn black marks onto the bulb.

NEC_NP-M230XG_projector_tighten_NEC_NP16LP_projector_lamp_screws

Push the top center on the projector lamp to secure it. Tighten the screw on the projector lam

NEC_NP-M230XG_projector_replace_lamp_cover_NEC_NP16LP_projector_lamp

Re-attach the NEC NP-M230XG lamp cover by sliding the cover until it snaps into place. Tighten the screw on the lamp cover.

Replacing the filters

There are four filters in the NEC NP-M260XG projector:

  • Honeycomb hard filter – large and small
  • Accordion soft filter — large and small

Replace all four filters at the same time. Before replacing the filters wipe off any dust and dirt that came loose from the old filters. NOTE: The filters are made with two different types of material in the membrane. Both perform the same.

NEC_NP-M260XG_projector_lamp_NEC_NP16LP_remove_air_filterPush the catch to release the NEC NP-M260XG filter and gently pull it out.



NEC_NP-M260XG_projector_lamp_NEC_NP16LP_detach_filter_cover

The filter cover is fixed at six separate points in the projector. Bow the filter cover by pushing it slightly until it releases.



NEC_NP-M260XG_projector_lamp_NEC_NP16LP_replace_dark_filtersRemove the dark sponge filter and clean the filter unit and cover. Attach the new non-woven white material filters.

NEC_NP-M260XG_projector_lamp_NEC_NP16LP_replace_four_filters

  • Filter unit: Attach two honeycomb hard filters to the NEC NP-M260XG filter unit.
  • Filter cover: Attach the two accordion soft filters to the filter cover. Be sure to align the accordion slits with the protrusions of the filter cover.



NEC_NP-M260XG_projector_lamp_NEC_NP16LP_attach_filter_coverAttach the filter cover back to the filter unit. Align the filter until with the filter cover and push the protrusions into place. Make sure all the six mounting points are aligned properly.



NEC_NP-M260XG_projector_lamp_NEC_NP16LP_attach_filter

Insert the two catches of the top of the filter into the groove of the cabinet. Push the filter until it clicks into place.



Reset the lamp timer

Once the NEC NP15LP projector lamp and NEC NP-M260XG projector filter have both been replaced you will need to reset the timer for both. You want the projector to be able to accurately track the projector lamp life.

NEC_NP-M260XG_projector_lamp_NEC_NP16LP_lamp_timer

Clear usage hours and reset hours

  • Plug in the power cored into the wall outlet.
  • Turn on the projector.
  • From the MENU select RESET.
  • Choose CLEAR LAMP HOURS.
  • A confirmation message appears.
  • Select YES.

Reset the filter hours:

  • Scroll up to CLEAR Filter HOURS.
  • A second submenu will appear.
  • Select YES. Press the ENTER button.

Extending the life of the NEC NP15LP projector lamp

Get your newly installed NEC NP15LP projector lamp will last longer by choosing the ECO option. The ECO MODE increases projector lamp life by lowering the power consumption. There are three modes to choose from:

  • Auto Mode: 4000 hours
  • Normal: 5000 hours
  • Eco ModeL 8000 hours

Learn more tips to extend the life of the NEC NP15LP lamp.

Tagged with: , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

Panasonic_PT-D5600UL_projector_Panasonic_ET-LAD55Follow this step-by-step instructional guide will help you install an new Panasonic PT-D5600UL projector lamp.

When to replace

Depending on the working conditions and setting of the Panasonic PT-D5600UL, projector lamp life may vary. The Panasonic PT-D5600UL uses the Panasonic ET-LAD55 projector lamp power and at 1300 hours the “Replace Lamp” warning is displayed on screen for 30 seconds. That message will be permanently displayed on screen until the Panasonic ET-LAD55 projector is changed. Don’t leave the lamp  as is after the warning message or the projector will automatically shut off and the so the Panasonic PT-D5600UL projector will enter a standby state. It will remain in standby state until the projector lamp is changed.

Choosing projector lamp options

The Panasonic PT-DW5000U comes equipped with two Panasonic ET-LAD55 projector lamps. You have the option of using:

  • SINGLE projector lamp mode: Either of the projector lamp is used – projector automatically chooses the lamp with the shorter operating hours.
  • DUAL projector lamp mode: Both projector lamps are used.
  • Projector LAMP1 : Lamp Unit 1 is always used alone.
  • Projector LAMP2 : Lamp Unit 2 is always used alone.

When only one Panasonic ET-LAD55 projector lamp is used (SINGLE, LAMP1 or LAMP2 options) and it’s been used for 1500 hours consecutively, the Panasonic PT-DW5000U projectors automatically switches to the second lamp. When both Panasonic ET-LAD55 lamps are used simultaneously for 1300 hours straight, the projector will automatically go into standby mode. Create longer projector lamp life by controlling the luminance of the projector lamp:

  • HIGH: Use when you need high brightness is necessary. Both lamps are used with this setting.
  • LOW: Set when high brightness is not necessary. This reduces power and operating noise while using only one lamp.

The importance of authentic lamps

It’s easy to get duped into buying an inferior knock-off lamp posing as an authentic lamp. Buyer beware! Always look for the seal of approval and watch for telltale signs you are about to purchase a counterfeit lamp

Find this lamp sold on Amazon by these authorized dealers:

Replacing the Panasonic ET-LAD55 projector lamp

Before replacing the Panasonic ET-LAD55 projector lamp follow these important safety step:

Panasonic-PT-DW5600UL_ET-LAD55_projector_lamp_turn_off

Panasonic-PT-DW5600UL_ET-LAD55_projector_lamp_turn_off_step3

1. Press the POWER OFF button on the Panasonic PT-D5600UL projector.

2. Select OK using the right or left arrows on the control panel. Press the ENTER button. (Or press the POWER OFF button again. The power indicator will light up orange.

3. Wait until the power indicator turns red and the cooling fans stop running on the Panasonic PT-D5600UL.

4. Press MAIN POWER to OFF.

Projector lamp installation steps:

1. Remove the power plug and wait for at least 45 minute for the projector to cool.

Panasonic-PT-DW5600UL_Lamp_ONE_ET-LAD55_projector_lamp_change2. Using a Phillips screwdriver, remove the screw securing the Panasonic PT-D5600UL projector lamp cover. Slide the lamp unit cover toward the left to remove it. (See diagram #2)

3. Remove the two screws securing the fan unit. (See diagram #3)

4. Gently open the fan unit in front of the both Panasonic ET-LAD55 projector lamps. (See diagram #4)

5. Remove the screws holding the Panasonic ET-LAD55 projector lamp in place. (Each lamps has two screws. Take hold of the wire handle and gently remove the projector lamp. (See diagram #5)

NOTE: The Panasonic ET-LAD55 projector lamp contains mercury and should not be thrown into regular garbage. Recycle this projector lamp!

6. Install the new lamp unit taking care not the touch the actual project lamp bulb as oil from your fingers will remain on the bulb and burn black spots when the projector lamp heats up.

7. Use a Phillips screwdriver to securely tighten each of the two screws on both projector lamps. Panasonic-PT-DW5600UL_finish_installation_ET-LAD55_projector_lamp

8. Put the fan back in place and tighten the two screens to hold it in place. (See diagram #8)

9. Slide the cover a little toward the right, and secure it by tightening the screw. (See diagram #9) NOTE: Firmly install the projector lamp unit and projector lamp cover. If not installed properly, the protection circuit will be activated and the projector will not turn back on.

Resetting the projector lamp timer

Each time you switch to a new Panasonic ET-LAD55 projector lamp you need to reset the Panasonic PT-DW5600UL projector lamp timer. Panasonic-PT-DW5600UL_ET-LAD55_reset_projector_lamp_timer

  • Insert the power cord plug into the wall outlet and then press the MAIN POWER switch.
  • Press the “ I ” button on the remote control to display an image picture onto the screen.
  • Press MENU to display the MAIN MENU screen.
  • Scroll down to select OPTION2. Press ENTER to display the OPTION 2 menu.
  • Scroll down to SYSTEM INFORMATION. Press ENTER to display the SYSTEM INFORMATION menu.
  • Press and hold the ENTER button on the projector or the remote control for approximately 3 seconds. The option LAMP TIME RESET will be added to the menu.

Scroll down to select the projector that has was replaced. Select the lamp which has been changed

  • LAMP1: Replace the LAMP UNIT 1
  • LAMP2: Replace the LAMP UNIT 2
  • Press ENTER.
  • When the LAMP TIME RESET display flashes, press ENTER again.
  • The used hours of the specified lamp unit will be reset to zero.
  • Press the MENU button to leave the LAMP TIME RESET menu.

Quick reset:

  • When lamp unit 1 has been replaced: In standby mode, press the number buttons in the sequence of 737381, and then press ENTER.
  • When lamp unit 2 has been replaced: In standby mode, press the number buttons in the sequence of 737382, and then press ENTER.
  • When the projector lamps hours have been reset, the lamp monitor (LAMP1/LAMP2) will flash for 3 seconds.

Learn more tips for extending the projector lamp life in your Panasonic PT-DW5600UL projector.

Tagged with: , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

Eiki_LC-WB40N_projector_Eiki_610-333-9740_POA-LMP111_projector_lampChange your Eiki LC-WB40N projector lamp in three simple steps. Follow our guide.

Step 1: Buy the right lamp

Always install an authentic Eiki LC-WB40N projector lamp in your Eiki LC-WB40N to keep it working properly. It uses a Eiki POA-LMP111 projector lamp. Avoid generics for the following reasons:

Go with original OEM projector lamps and save yourself hassles.

Find this lamp sold on Amazon by these authorized dealers:

Step 2: Recognize end of life warnings

The Lamp Management Function detects the status of the projector lamps and triggers the Lamp Replace Indicator to start blinking yellow.

Eiki_LC-WB40N_Eiki_610-333-9740_POA-LMP111_projector_lamp

Other indicators of an Eiki POA-LMP111 projector lamp needing a replacement include faded images on screen, distorted colors and a general decline on the overall picture. Change the Eiki POA-LMP111 projector lamp immediately whenever any of these symptoms start appearing.

Step 3: Replacing the Eiki POA-LMP111 lamp

Follow these important safety steps before replacing the Eiki POA-LMP111 projector lamp:

  • The Eiki LC-WB40N projector operates under very high temperatures. Let it cool for one full hour before attempting to replace the lamp in order to avoid being burned.
  • Turn off the projector by pressing the power button. Wait for the light to stop flashing.
  • Turn off the power switch at the back on the projector
  • Unplug any power cords.

Eiki_LC-WB40N_Eiki_610-333-9740_POA-LMP111_install_replacement_projector_lamp

  • Loosen the screw on Eiki LC-WB40N Lamp Cover and remove Lamp Cover.
  • Loosen the 2 screws holding the Eiki POA-LMP111 projector lamp in place. Using the two handles on either side of the projector lamp and gently lift it out of the projector. Pulling too quickly can cause the bulb to shatter. Learn what to do should the bulb shatter.
  • NOTE: The Eiki POA-LMP111 projector lamp contains mercury and should be properly recycled. Don’t place it into regular garbage.
  • Place a new projector lamp into the Eiki LC-WB40N making sure not to touch the actual bulb. Finger prints on the bulb will be burned into the glass when the projector heats up.
  • Tighten the 2 screws on the new lamp
  • Replace Lamp Cover and tighten the screw.
  • Connect AC Power Cord to a projector and turn projector on.
  • Reset Lamp Replacement Counter.

Reset Eiki LC-WB40N lamp counter

Your Eiki LC-WB40NA projector has a built in lamp counter to determine when the projector lamp should be replaced. It needs to be reset every time you replace the Eiki POA-LMP111 projector lamps. When the Lamp Replace Counter is reset, the LAMP REPLACE indicator stops lighting.

Eiki_LC-WB40N_Eiki_610-333-9740_POA-LMP111_reset_projector_lamp_counter

  • Turn projector on, press MENU button and ON-SCREEN MENU will appear.
  • Press POINT LEFT/RIGHT button(s) to move the red frame pointer to SETTING Menu icon. Press POINT DOWN button to move a red frame pointer to “Lamp counter reset.”
  • Press SELECT button.
  • Move arrow to select either Lamp 1 or Lamp 2. Press SELECT button.
  • Message “Lamp replace counter Reset?” is displayed.
  • Move pointer to YES and then press SELECT button.
  • NOTE: Be sure to reset correct lamp number otherwise LAMP REPLACE indicator continues lighting.
  • Another confirmation dialog box appears and select YES to reset Lamp Replace Counter.
  • Do not reset Lamp Replace Counter except after Projection lamp is replaced.

Extend the life projector lamp life

Get more hours from your Eiki POA-LMP111 projector lamp by following these maintenance tips:

  • Keep your air filters clean to avoid overheating the projector.
  • Turn off the Eiki LC-WB40NA projector and let it stand unused for at least one hour ever 24 hours. An average use of four to five hours per day will ensure longer lamp life.
  • Make sure there is enough airflow around the projector particularly if it’s been permanently mounted.
  • Learn more with Top tips for extending DLP projector lamp life.
  • Press the MENU button to exit.
Tagged with: , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

Boxlight_Phoenix_S30_Boxlight_PHOENIXS25-930_projector_lampChanging your Boxlight Phoenix S30 projector lamp is simple when you follow this guide.

Watch for end of life

Signs that your Boxlight Phoenix S30 projector lamp is reaching its end of life include:,

  • the Power LED flashing consecutively five times
  • at the same time the Ready LED flashes once.
  • image becoming darker
  • color becoming unnatural.

Change the OEM Phoenix S25-930 projector lamp lamp immediately when any of these symptoms appear.

Get the right projector lamp

Your Boxlight Phoenix S30 projector uses high-end optics that need to work with an OEM Phoenix S25-930 projector lamp designed to be compatible with those optics. Look for the seal of approval when buying. Counterfeit lamps may look like a bargain but cost you more in the long run. Counterfeit lamps have many problems:

Find this lamp on Amazon sold by these authorized dealers:

Replacing the Phoenix S25-930 projector lamp

Before replacing the Phoenix S25-930 projector lamp follow these safety tips:

  • Disconnect the power cord on the Phoenix S30 projector
  • Reduce the risk of severe burns by allowing the Phoenix S30 projector to cool for at least one hour. These projectors operate using high temperatures and you run the risk of severe burns if you don’t allow it to cool down.

Boxlight_Phoenix_S30_Boxlight_PHOENIXS25-930_projector_lamp_remove_lampBoxlight_Phoenix_S30_Boxlight_PHOENIXS25-930_projector_lamp_loosen_cover_screws



  • Loosen the two top screw holding the lamp cover in place.
  • Open the projector cover.







Boxlight_Phoenix_S30_Boxlight_PHOENIXS25-930_projector_lamp_install_replacement



  • NOTE: Be sure to recycle the projector lamp as contains mercury and should not be thrown into regular garbage. Recycle it!
  • Insert the new Phoenix S25-930 and avoid touching the actual bulb as this can result in black spots from the oil on your hands.
  • Tighten the two screws on the Phoenix S25-930 projector lamp
  • Place the cover back onto the Boxlight Phoenix S30 projector and tighten the lamps screw. You must now reset the lamp timer.

Resetting the Boxlight Phoenix S2 lamp counter

Boxlight_Phoenix_S30_Boxlight_PHOENIXS25-930_projector_lamp_reset_timerOnce the PhoenixS25-930 projector lamp has been replaced, you will need to reset the lamp counter so the Phoenix S30 projector can accurately track the number of lamp hours remaining:

  • Turn the projector on.
  • Press the MENU button. The ON-SCREEN MENU will appear.
  • Press the POINT LEFT/RIGHT buttons to move across the top menu. Select STATUS.
  • Press the POINT DOWN button and scroll down to LAMP HOUR. Press ENTER.
  • Lamp hours will be set to zeto.

Extend the life of the Phoenix S25-930 projector lamp by always keeping the air filters clean so the projector doesn’t overheat. The Eco modes for the lamp setting uses less power by decreasing lamp brightness and extending lamp life. Read more with Top tips for extending DLP projector lamps.

Interested in a green alternative?

Boxlight_Phoenix_S25_Boxlight_PHOENIXS25-930_ecofriendly_projector_lamp_install_replacement

With the Phoenix S25 projector you also have the option of just replacing the actual bulb to re-use the plastic cage. This reduces waste and is a great way to green your projector. Watch our training video to learn more.







Tagged with: , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

Optoma_PRO350_Optoma_BL-FU185A_SP.8EH01GC01_projector_lampThis quick guide will show you how to install a new projector lamp for your Optoma PRO350 projector.

The Optoma PRO350 projector uses the Optoma BL-FU185A. When the Optoma PRO350 projector lamp has reached end of life,  the lamp warning message flash on screen. This means you have no more than 30 hours before the bulb will burn out. You may aslso notice the Lamp-LED light flashing red and the picture quality starting to get poor resolution.

Optoma_PRO350_lamp_replacement_warning_BL-FU185A_projector_lamp

Change the Optoma BL-FU185A projector lamp in your Optoma PRO150S immediately.

Authentic projector lamps are critical!

You’ll want the best projector lamp for your Optoma PRO350 and that means buying directly from an authorized manufacturer. Look for the seal of approval. Avoid generic lamps for the following reasons:

Learn how to spot copycat lamps posing as authentic lamps.

Find this lamp on Amazon sold by these authorized dealers:

Installing the Optoma BL-FU185A projector lamp

Before replacing the Optoma BL-FU185A projector lamp follow these crucial safety tips to prevent injury to yourself or the projector:

  • Switch off the power to the Optoma PRO350 projector by pressing the Power/Standby button.
  • Disconnect the power cord.
  • Allow the projector to cool down for at least 30 minutes. If should be cool to the touch. These projectors run using high temperatures and you can burn yourself badly if you don’t allow the projector to cool down.

Optoma_PRO350_Optoma_BL-FU185A_SP.8EH01GC01_change_projector_lamp1. Use a screwdriver to undo the two screws holding the lamp cover in place. The screws on the lamp cover and the lamp cannot be removed.

2. Remove the lid and place to one side. Don’t lose the lid as the PRO350 projector will not turn back on until the lamp cover has been properly installed.

3. Remove the two screws holding the Optoma BL-FU185A projector lamp in place.

Note: The used Optoma BL-FU185A  projector lamp contains mercury and should be properly recycled.

4. Lift up the wire handle on the Optoma BL-FU185A  projector lamp and slowly remove it from the projector. Be careful not to bang the lamp against the projector as this may case the bulb to break. Learn what to do if the lamp has exploded inside the projector.

Install the new Optoma BL-FU185A  projector lamp:

  • Remove the new Optoma BL-FU185A projector lamp from its packaging.
  • Taking care not to touch the actual bulb, lift up the handle on the new lamp and insert it gently into the Optoma PRO350 projector.
  • Tighten the two screws on the projector lamp.
  • Replace the lamp cover and tighten its two screws. Reset the lamp timer.

Reset the Lamp Replacement Timer

The Optoma PRO350 projector has an automatic lamp timer that tracks the numbers of hours left in the projector lamp. When the Optoma BL-FU185A (SP.8EH01GC01) projector lamp is approaching end of life, the lamp replacement timer will trigger the warning system. If you don’t reset the lamp replacement timer you run the risk of the projector lamp being used beyond its recommended life and possibly exploding in the projector.

Optoma_PRO150S__reset_lamp_timerBL-FU185A_projector_lampTo reset the Lamp Replacement Timer:

  • Turn on the projector.
  • Using the remote press MENU
  • Select OPTIONS
  • Select LAMP SETTINGS
  • Select LAMP RESET
  • Select YES.
  • Press MENU to exit.

Extend the life of the Optoma BL-FU185A projector lamp:

  • Chose the “STD” mode to to dim the projector lamp and lower power consumption. This will extend the lamp life by up to 130%.
  • Keep your air filters clean to avoid overheating the projector.
  • Every 24 hours, turn off the projector and let it stand for 1 hour
  • Make sure there is enough airflow around the Optoma PRO350 projector particularly if it’s been permanently mounted.

Learn more with Top tips for extending DLP projector lamp life.

Green your Optoma PRO350 projector

Optoma-BL-FU185A_replacement_bulb_training_videoThe Optoma PRO350 projector has the option of re-using the existing lamp cage and replacing only the actual bulb. You recycle and reduce waste this way. Watch our Optoma BL-FU185A training video to learn more.

Tagged with: , , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

Epson_PowerLiteEB-S9_projector_Epson_ELPLP58_projector_lampDon’t panic when its time for a new Epson EB-S9 projector lamp. This step-by-step guide shows you how to install a new projector lamp.

Step 1: Buy an authentic

Epson ELPLP58 (V13H010L58) is the official projector lamp used in the Epson EB-S9 projector. You may be tempted to buy a cheaper Epson EB-S9 projector lamp in order to save money. While these knock-off lamps appear to be a bargain, they will actually end up costing you more.

Six reasons to avoid generics

Step 2: Watch for end life signs

Epson_EB-S9_projector_Epson_ELPLP58_check_projector_lamp_hoursWhen you see the projector lamp indicator flashing orange, it’s time to change the Epson EB-S9 projector lamp is reaching end of life. You may also see the Replace the lamp message on screens. Other indications are screen gets darker or starts deteriorate altogether.

Epson_EB-S9_projector_Epson_ELPLP58_projector_lamp_lamp_warning In order to maintain projector brightness and image quality, replace with a new Epson LPLP58 (V13H010L58) projector lamp as soon as possible.

The Epson EB-S9 projector lamp can last for close to 4,000 hours when the power consumption is set to NORMAL and up to 5,000 hours if the ECO option is used. You can check the hours left on the ELPLP58 (V13H010L58) projector lamp from the INFO Menu access off the Main Menu.

Installing a new ELPLP58 (V13H010L58) projector lamp

Before replacing the ELPLP58 (V13H010L58) projector lamp follow these important safety rules:

  1. Always unplug the power cord on the Epson EB-S9 projector before replacing the projector lamp.
  2. This projector operates using high temperature. Wait at least 60 minutes before replacing the lamp so you don’t run the risk of getting burned.
  3. Never touch the bare projector lamp bulb as the oil from your fingers will burn black marks onto the projector lamp when it heats up.
  4. Never operate the Epson EB-S9 projector with the projector lamp removed.

Epson_PowerLite_EB-S9_Epson_ELPLP58_remove_projector_lamp_cover

Remove the projector lamp cover screws and place to one side.

Epson_EB-S9_projector_Epson_ELPLP58__remove_projector_lamp_screwsLoosen the two screws holding the Epson ELPLP58 (V13H010L58) projector lamp in place (you can’t remove them).

Epson_EB-S9_projector_Epson_ELPLP58_install_new_projector_lamp

Gently lift out the Epson LPLP58 projector lamp taking care not to bang it against the projector. NOTE: The LPLP58 projector lamp contains mercury and should not be thrown into regular garbage. Recycle this lamp!

Gently insert the new Epson LPLP58 projector lamp. Make sure it fits into the Epson EB-S9 projector properly. (Check that it’s facing the right way.) Tighten the Epson LPLP58 projector lamp.

You can know reset the lamp timer.

Reset the lamp timer

Epson_EB-S9_projector_Epson_ELPLP58_reset_projector_lamp_timer

After you replace the lamp, you need to reset the Epson EB-S9 projector lamp timer using the projector’s menu system.

  • Press the MENU button on the remote control or on the projector’s control panel. You see the main menu.
  • Select the RESET menu. Press ENTER.
  • Scroll down to select RESET LAMP HOURS. Press ENTER.
  • A prompt filed appears asking if you want to reset the lamp timer. Select YES. Press ENTER.
  • Press MENU to exit.

Longer life for the ELPLP58 (V13H010L58) projector lamp

Extend the life of the Epson ELPLP58 (V13H010L58) projector lamp with the following tips:

  • Set the Power Consumption to ECO option.
  • Clean the air filters regularly so the Epson EB-S9 projector doesn’t overheat.
  • Make sure there is enough airflow around the projector.
  • Turn it off when it’s not in use.
  • Learn more: Top tips for extending DLP projector lamp life.
Tagged with: , , ,

by avatarShelagh McNallyPosted on Posted in FixYourDLP, Projector Lamp Replacement Guides — No Comments ↓

This guide can hAcer X1230_projector_Lamp_Acer_EC_J9000-001elp when its time to replace Acer X1230 projector lamp.

Replace the Acer X1230 projector lamp when you see the following warning message: Lamp is approaching the end of its useful life in full power operation. Replacement Suggested!”

Be prepared with an authentic projector lamp

Your Acer X1230 needs an authentic Acer EC.J9000.001 lamp in order to keep working properly. Cheap knock-offs  have a much shorter lamp life and are prone to explosions. Since copycat manufacturers don’t have access to the proper materials, generic lamps are created with toxic materials that pose a health threat. Authentic OEM acome with a money-back guarantee as well as keeping your warranty intact. Protect yourself from buying counterfeit lamps.

Find this lamp on Amazon sold by these authorized dealers:

Installing a  new Acer EC.J9000.001 projector lamp

Before installation follow these important safety steps:

  • Turn off the Acer X1230 projector and unplug the AC cord.
  • These projectors operate under high temperatures and there is a risk of burning if the projector has not cooled enough. Allow the Acer X1130 to cool for one hour. It should be cool to the touch.


1. Remove the two screws from the cover. Lift the cover off the projector and place it to one side.

2. Remove the two screws holding the Acer X1230 projector lamp in place. screw from the cover.

3. Lift the wire handle on the Acer EC.J9000.001 bulb and gently pull the lamp up to remove it.

Don’t throw the old Acer EC.J9000.001 projector lamp projector lamp into regular garbage as it contains mercury — send it to a local recycling program.

4. Take the new Acer EC.J9000.001 projector lamp projector lamp using the wire handle. Avoid touching the bare bulb; the oil on your finger can leave a black mark on the lamp affecting the projected image. Tighten the screws on the new Acer EC.J9000.001 projector lamp.

Put the lid back onto the projector. Tighten the screw holding the lid in place. Plug the AC cables back into the projector. Turn the project on so you can reset the lamp timer.

Resetting the projector lamp timer

It’s important to always reset the lamp timer after replacing the projector lamp in your Acer X1230 projector. You want the projector to track how many hours the lamp has been used and send out warning messages when the Acer EC.J9000.001 reaches end of life.





Acer-X1230_projector_Lamp_Acer_EC_J9000-001_reset_lamp_timerTo reset the Projector Lamp timer:

  • Open the MAIN MENU. Press ENTER.
  • Scroll down to the MANAGEMENT menu. Press ENTER.
  • Scroll down to the Lamp Hour reset option.
  • Press the right arrow.
  • The lamp will be reset to zero.

Extending the projector lamp life

Learn more tips for extending lamp life.



A green alternative

Acer-X1230_projector_change_bulb_Lamp_Acer_EC_J9000-001



The Acer X1230 projector has the option of also just replacing the actual bulb and re-use the plastic cage. This reduces waste and is a great way to green your projector.

Watch our training video to learn more.

Tagged with: , ,
Join the discussion on Facebook! All your questions, answered! The Screen & Projector Group
