Epson PowerLite 1222_projectorWhen to replace the  Epson PowerLite 1222 air filter?

The Epson PowerLite 1222 air filter is an important part of helping to keep your projector working properly. It keeps out the dust and dirt from getting inside  but also helps the air circulate so your projector doesn’t overheat. Clean air filters can help your projector lamp last longer.

Cleaning the Air Filter and Vents

Epson_PowerLite_ 1222_clean_air filterCleaning the air filters should be a regular part of your projector maintenance  but it you forget you will see an onscreen message telling you to clean them. Follow these steps:
1. Turn off the projector and unplug the power cord.
2. Gently remove the dust from the Epson PowerLite 1222 air filterusing a small vacuum designed for computers or a very soft brush (such as a paintbrush). DON’T use canned air since this leaves a flammable residue in the projector. The canned air can also push dust into the projector’s sensitive optics and damage them.
3. If the filters are very blocked with dust you can remove them to clean both side. DON’T use any water, detergent or cleaning solutions on the filter.
4. If there is too much dust or if the Epson PowerLite 1222 air filter is damaged, you will need to replace it. After cleaning the air filter, you may also see a message telling you to clean or replace it

Find this air filter on Amazon:

OEM Epson Projector Air Filter: PowerLite 1222, 1224, 1263W, 1264, 1284

Replacing the air filter

Epson PowerLite 1222_replace air filter_lid
You can replace the Epson PowerLite 1222 air filterwhile the projector is mounted to the ceiling or placed on a table.
1. Turn off the projector and unplug the power cord.
2. Carefully open the air filter cover.







Epson_PowerLite_1222_remove_air_filter
3. Pull the Epson PowerLite 1222 air filter out of the projector.
Note: Air filters contain ABS resin and polyurethane foam so need to be disposed properly. Don’t thrown them into regular garbage.







Epson_PowerLite 1222_install_new_air_filter4. Place the new Epson PowerLite 1222 air filter in the projector as shown and push gently until it clicks into place.
5. Close the air filter cover.



Also check the projector lamp life. Often the lamp needs to be replaced at the same time as as the filter.





Learn more about:

flame-projector lamp overheated

Solve your projector heat problems

Stop your projector from overheating. Projector heat problems are common to every type of projector. Almost all projectors face problems with overheating. Whether yours is using an LCD or a DLP projector lamp, there is a tremendous amount of heat created—close to 200 to 300 degrees Th.e brighter and clearer the projection, the higher the heat. These tips will help your projector stay cool.

projector heat problems

Air flow

Uninterrupted airflow outside the projector is the most important thing to consider when installing your projector. There has to be enough space around the projector so air can circulate freely. Don’t place it atop any soft surfaces and make sure there is nothing blocking the sides.

Clean air is also important. If you are running your projector is an extremely dusty or smoky room, it is going to heat up much quicker. Cigarette smoke will definitely make the projector heat up quicker. If the room is extremely smoky, then you will need to check the air filters more frequently.

projector heat problems -- ceiling mountsProper placement

Placement is really important to keep the fans and air vents working. Keeping the area around the projector free from clutter will help the projector to stay cool and prevent any unplanned shutdowns due to heat buildup.

When using the projector on a table or desk make sure that there nothing blocking the vents. Never cover the projector when it’s operating as this can cause it to overheat as well. The heat from the projector has nowhere to go since it’s being created inside.  If you are mounting the projector leave enough space between the ceiling and projector to have air flow.

air filtersBasic Cleaning

Most projectors rely on built in fans to remove heat from the projector. These fans circulate cool air around inside the projector. These fans also draw in air to cool down the projector.  To prevent dust from getting inside the projectors and to purify the air there are also air filters in front of the circulating vents. Over time these air filters become dirty. If they become too blocked then air can’t circulate, and the projector starts to overheat. You should always check your air filters on a regular basis. Depending on your model, you may need to replace the entire air filer rather than clean it. Also check the fan and if it needs to be cleaned. This is usually done with compressed air to blow the dust away from the fan.

match-Room Temperature

A climate-controlled room is the best environment for your projector. An air-conditioned room will keep the projector from overheating. Adjusting the temperature can help the projector stay cool.

Use the off switch

Your projector needs time to cool down. It’s recommended that after a presentation you turn off after letting it cool. This will also make the projector lamp last longer.  Sometimes connecting cables don’t provide the proper connections and this can cause heat problems as well. If you find your cables are heating up, then replace them with higher quality ones.

Top tips for extending projector lamp life

Tagged with: ,

InFocus IN124 projector

This easy to follow guide shows how to install a new InFocus IN124ST projector lamp

End of life warnings

When the InFocus IN124ST projector lamp is reaching end of life you’ll see the following warning signs:

  • On screen message: The lamp has reached the end of its usable life. Please replace the lamp.
  • LAMP indicator blinking red.
  • Screen colours looks off
  • Picture is faint or has deteriorated

Invest in authentic lamps

The best type of projector lamp for your InFocus IN124ST is one from a North American OEM. Despite their bargain prices, counterfeits often end up damaging the sensitive electronics in your projector since they are prone to explosions. The substandard toxic materials used give these counterfeit projector lamps a much shorter life as well. The other concerns are the lack of proper safety guards for your eyesight. Save yourself the hassles and buy authentic!

Find this lamp sold on Amazon by these authorized dealers:

Changing the projector lamp

Your InFocus IN124ST projector uses the InFocus SP-LAMP-083 projector lamp. Be sure to invest in an authentic lamp.
Follow these important safety instructions before installing the new InFocus IN124ST projector lamp

  • turn off the InFocus IN124ST projector.
  • unplug the projector from its power source.
  • unplug the power cable.
  • wait until the projector is cool to the touch to avoid getting burned.

InFocus IN124ST projector_lamp_SP-LAMP-083_remove_cover

Remove the lamp door, located on top of the projector, by removing the screw on the left side of the lamp door, sliding the door to the left and lifting the lamp door off.

InFocus IN124ST projector_lamp_SP-LAMP-083_new lamp

Loosen the captive screws that attach the InFocus SP-LAMP-083 lamp housing to the projector. NOTE: If the projector is installed on a ceiling mount, be careful not to drop the lamp module once the captive screws are loosened.  Carefully lift the lamp straight up, off of the alignment pins; being careful not to pinch the lamp connector.

NOTE: Your InFocus SP-LAMP-083 projector lamp should be properly recycled because it contains mercury.

Install the new lamp:

  • Place into the lamp housing
  • Aligning the pins properly. Be careful not to pinch the lamp connector.
  • Tighten the screws. (NOTE: If the pins have not been aligned properly, the screws will not tighten securely.)
  • Replace the lamp door locking it back into place.
  • Replace the lamp door screw and tighten securely.

You can now reset the lamp timer.

Reset the lamp timer

When you change the InFocus IN124ST projector lamp pyou will need to reset the timer in order for the lamp life to be accurately tracked.

InFocus_IN124ST projector_lamp_SP-LAMP-083_reset_lamp_timer

  • Plug in the power cord into the wall outlet.
  • From the MAIN MENU select ADVANCED MENU
  • Scroll to Status/Service menu
  • Select Reset Lamp Hours.
  • A confirmation message appears.
  • Select YES.
  • Learn more tips to extend the life of the InFocus SP-LAMP-083 projector lamp.

Save

Tagged with: , , ,

Optoma EzPro 731 projectorIt’s easy to replace your Optoma EzPro 731 projector lamp when you follow our guide.

When it is time to replace?

When the warning message: ““Lamp may fail soon ! ReplacementSuggested !”  appears, it’s time to replace the Optoma EzPro 731 projector lamp! Other warning signs that the Optoma EzPro 731 projector lamp is reaching end of life include the Lamp LED flashing orange or an image with bad color and deteriorating definition. Don’t wait! This projector needs the Optoma BL-FP150B replacement lamp.

Buy the right projector lamp

Be sure to buy an authentic projector lamp. Watch for telltale signs you are about to purchase a counterfeit lamp:

Six reasons to avoid generics

Buy this lamp on Amazon from the following authorized dealers:

Installing the Optoma BL-FU200A projector lamp

Before replacing the projector lamp be sure to follow these important safety tips:

  • Switch off the power to the projector by pressing the Power/Standby button.
  • Allow the projector to cool down for at least 30 minutes. It should be cool to the touch. The EzPro 731 runs at a high temperature and you can burn yourself badly if you don’t allow the projector to cool down.
  • Disconnect the power cord.

Optoma_EzPro 731_projector_lamp_BF150

  • Step 1: Placing the Optoma EzPro 731 on a soft surface, turn it upside down. Loosen the screw holding the lamp cover in place.
  • Step 2: Remove the cover and screw. Put to one side.
  • Step 3: Loosen the three  screws holding the Optoma BL-FP150B projector lamp in place. Using the wire handle, gently lift the projector lamp out of the projector.
  • NOTE: The Optoma BL-FP150B projector lamp contains mercury and should not be thrown into regular garbage. Recycle this lamp.
  • Step 4: Insert the new Optoma BL-FP150B projector lamp into the projector and tighten the screws. Take care not to touch the actual bulb as the oil from your fingers will burn black marks onto the lamp.
  • Step 5: Replace the Optoma BL-FP150B projector lamp cover and tighten the three screws holding it in place.
  • Step 6: Align the top cover. Replace the screw and tighten into place.
  • Step 7: Turn on the projector. You are now ready to reset the lamp timer since the projector lamp has been replaced. NOTE: If the lamp timer is not reset the projector will keep shutting itself off thinking the projector lamps has reached end of life.

Reset the Optoma EzPro 731 lamp timer

Your Optoma EzPro 731 comes equipped with an automatic lamp timer that tracks the number of hours left for the Optoma BL-FU200A lamp. Each time you change the lamp you need to reset the lamp timer. Failure to do so may cause the projector to use the lamp over the recommended period of time resulting in the lamp exploding.

Optoma_Ezpro 731_reset_lamp_timer

  • Press the Menu button to open the On-Screen-Data (OSD) menu.
  • Scroll over to the Management menu.
  • Scroll down to Lamp Reset.
  • Press the right arrow or Enter button to enter Status menu.
  • Move down to Lamp Hour Reset.
  • Press the right arrow or Enter button to select Reset option.
  • The Status menu appears again showing the Lamp Hours reset to zero.

TOP Tips for extending the projector lamp life

  • Turning on the Eco Mode to lower power consumption and extend the lamp life by 130%.
  • Keep your air filters clean to avoid overheating the projector.
  • Turn off the Optoma EzPro 731 projector and let it stand for at least one hour ever 24 hours.
  • Make sure there is enough airflow around the projector particularly if it’s been permanently mounted.
  • Top tips for extending DLP projector lamp life
Tagged with: , ,

Mitsubishi WD-62525 projector TV lampYour guide to installing a new Mitsubishi WD-62525 TV projector lamp

The best investment you can make to keep your Mitsubishi WD-62525 TV working at its best is to buy an authentic TV projector lamp.

Replacing the projector lamp

If you notice the picture is dimming or the color brightness change, it’s time to replace the projector TV lamp. Be sure to buy an authentic lamp from an authorized dealer to keep your TV working. Knock-off counterfeit lamps have a shorter lamp life and have been created with toxic substitutes and are prone to explosions that s often damage the sensitive electronics in your projectors. Invest in authentic.

Find this lamp sold by these authorized dealers on Amazon:

Changing the projector lamp

Your Mitsubishi WD-62525 TV uses the 915P020010 TV projector lamp. Before replacing the projector lamp, please follow these safety precautions.

  • Reduce the risk of electrical shock by disconnecting the power cord on the Mitsubishi WD-62525 TV
  • Reduce the risk of severe burns by allowing the TV to cool for at least 45 minutes. It should be cool to the touch.

Replacing the Lamp Cartridge
Mitsubishi WD-52525-remove speaker

Tool needed: Phillips screwdriver
1. Turn the television off and unplug the AC cord.
2. Remove the front speaker grill by gently pulling on each side. The grill will snap out.

Mitsubishi WD-52525-remove old lamp
3. Using a phillips screwdriver, remove the three screws (one on the left and two on the right side)
that hold the recessed plastic cover in place.
4. Remove the plastic cover and set aside with the screws.

Mitsubishi WD-52525-install newlamp
5. After removing the cover, you will be able to see the lamp cartridge. With the screwdriver, loosen the three screws of the cartridge. The three screws will not completely remove.
6. Gently grasp the metal handle and pull straight out (towards you).
7. Insert the new lamp cartridge securely into the TV. Do not touch the glass surface of the cartridge.
8. With the screwdriver, tighten the screws on the lamp cartridge.
9. Replace the plastic cover and screws.
10. Snap the speaker grill back into place by pushing it into place on each side with the palm of your hand.

Resetting the Lamp Hour Timer

It’s important to only reset the lamp timer when you replace the Lutema 915P020010 projector lamp.

To reset:

  • Press the “System/Reset” button on the TV’s control panel. The green LED on the panel will flash for up to 90 seconds.
  • Press the “Power” button to turn the TV on when the green LED stops flashing.

Extending the life of the projector lamp:

Tagged with: , ,

Optoma DH1017 projectorHow to replace the Optoma DH1017 projector

When it’s time to replace the Optoma DH1017 projector lamp you’ll notice the picture quality is diminishing or the color appears off. The projector automatically detects the lamp life. When the lamp life is nearing the end of use, you’ll also receive a warning message. Replace the lamp immediately.

Optoma_EH500_projector_Optoma_BL-FU310B_lamp_warning

Go with authentic

With so many choices, it can be confusing finding the correct projector lamp online. In order to keep your Optoma DH1017 projector working at its best, be sure to look for an OEM manufactured lamp. You’ll need Optoma BL-FU310B projector lamp. Since this is an older model,  you may need to go with a generic lamp. Avoid counterfeits because of the associated problems:

Find this lamp on Amazon sold by these authorized dealers:



Installing the projector lamp

Before installing the Optoma DH1017 projector lamp follow these safety precaution

  • Turn off the projector
  • Unplug the power cord
  • Allow the Optoma DH1017 projector to cool down for at least 30 minutes. If should be cool to the touch to prevent to getting burned.

To install the lamp

  • Remove the button covering the cover screw. Loosen to screw to remove the projector cover
  • Optoma_EH500_projector_Optoma_BL-FU310B_remove_lamp
  • Slide the top cover forward, and lift the top cover off.
  • Remove the screw on the Optoma BL-FU310B projector lamp cover and then open it up.
    Loosen the four screws from the Optoma BL-FU310B projector lamp.

Optoma_EH500_projector_Optoma_BL-FU310B_replace_projector_lamp

  • Raise the handle and pull out the Optoma BL-FU310B projector lamp. NOTE: The Optoma BL-FU310B projector lamp contains mercury and should not be thrown into regular garbage. Recycle this lamp.
  • Insert the replacement Optoma BL-FU310B projector lamp.
  • Tighten the four screws on the lamp.
  • Replace the project cover and tighten the screw.
  • You are now ready to reset the lamp timer.

Reset the Optoma DH1017 lamp timer

Your Optoma DH1017 projector comes equipped with an automatic lamp timer that tracks the number of hours left on the projector lamp. Each time you change the lamp you need to reset the lamp timer.

Open the Options Menu from the Menu.
Optoma_EH500_projector_Optoma_BL-FU310B_lamp_hours

  • Scroll down to the Lamp Reset option.Press Enter.

Optoma_EH500_projector_Optoma_BL-FU310B_reset_lamp_timer

  • A second screen appears asking if you want to reset the lamp hours to zero. Scroll over and choose Yes. Press Enter. The lamp timer will be reset to zero.

Learn the TOP Tips for extending the lamp life in your Optoma DH1017 projector lamp projector.

Tagged with: , , ,

LG_BX286_projectorReplace the LG BX286 projector lamp with our guide

When it’s time to replace the LG BX286 projector lamp you’ll notice the lamp indicator starts flashing red. A warning sign will also appear stating that it’s time to replace the lamp.

LG_BX286_projector_LG AJ-LBX2B_lamp_warning

Why invest in authentic?

Prolong the life of your LG BX286 projector by installing an original projector lamp. Generic lamps look like a great bargain but have a number of problems. Your LG BS275 projector uses the LG AJ-LBX2B replacement projector lamp.

Reasons to avoid counterfeit lamps:

Find this authentic lamp on Amazon sold by these authorized dealers:


eWorldlamp LG AJ-LBX2B high quality Projector Lamp Original Bulb with housing Replacement for LG BW286 BX286

Installing the lamp

Before installation:

  • Turn off the LG BX286 projector and unplug the AC cord.
  • Allow the projector to cool for one hour – it should be cool to the touch. Inside of the projector can be very hot since these machines operator under high temperatures and you run the risk of being burned if the projector has not cooled down.
  • Do not operate the projectors while any of the lamps are removed as this may result in malfunctions, fire hazard and other accidents.

Caution: Don’t touch the screen or the actual bulb with your finger since the oil from your skin can cause a black spot on the bulb.


1. Use a screwdriver to remove the 2 screws from the cover. Push up and remove the cover.
2. Remove the 2 screws from the lamp module.
3. Pull up the lamp bar.
4. Pull out the lamp module by force. NOTE: The LG AJ-LBX2B lamp contains mercury and should not be thrown into regular garbage. Recycle your used lamp.

5. Install the new lamp module making sure to align it properly. Push the wire bar down.

6. Tighten the 2 screws on the lamp module.
6. Replace the lamp cover and tighten the two screws.

Reset the lamp timer

Reset the LG BX2865 projector only when the LG AJ-LBX2B projector lamp has been replaced.

LG_BX286_projector_LG AJ-LBX2B_lamp_reset_timer



  • Turn on the power.
  • Select MENU
  • Select OPTIONS/Lamp Settings
  • Scroll over to select Lamp Counter Reset



Extend the life of the newly installed lamp with the following tips:

  • Keep your air filters clean to avoid overheating the projector.
  • Turn off the LG BX286 projector and let it stand for at least one hour ever 24 hours. An average use of four to five hours per day will ensure longer lamp life.
  • Make sure there is enough airflow around the projector particularly if it’s been permanently mounted.
  • Learn more with Top tips for extending DLP projector lamp life



Tagged with: , , ,

LG BS275 projectorReplace the LG BS275 projector lamp with our guide

When it’s time to replace the LG BS275 projector lamp you’ll notice the lamp indicator starts  flashing red. A warning sign will also appear stating that it’s time to replace the lamp.

LGbs275_projector_lamp_warning

Why invest in authentic?

Prolong the life of your LG BS275H projector by installing an original projector lamp. Generic lamps look like a great bargain but have a number of problems. Your LG BS275 projector uses the LG AJ-LBX2A replacement projector lamp.

6 reasons to avoid counterfeit lamps:

Find this authentic lamp on Amazon sold by these authorized dealers;


AJ-LBX2A LG BS275 Projector Lamp

Installing the lamp

Before installation:

  • Turn off the LG BS275 projector and unplug the AC cord.
  • Allow the projector to cool for one hour – it should be cool to the touch. Inside of the projector can be very hot since these machines operator under high temperatures and you run the risk of being burned if the projector has not cooled down.
  • Do not operate the projectors while any of the lamps are removed as this may result in malfunctions, fire hazard and other accidents.

Caution: Don’t touch the screen or the actual bulb with your finger since the oil from your skin can cause a black spot on the bulb.

LGbs275_projector_lamp_replace


1. Use a screwdriver to remove the 2 screws from the cover. Push up and remove the cover.
2. Remove the 2 screws from the lamp module.
3. Pull up the lamp bar.
4. Pull out the lamp module by force. NOTE: The LG AJ-LBX2A lamp contains mercury and should not be thrown into regular garbage. Recycle your used lamp.

5. Install the new lamp module making sure to align it properly. Push the wire bar down.

6. Tighten the 2 screws on the lamp module.
6. Replace the lamp cover and tighten the two screws.

Reset the lamp timer

Reset the LG BS275 projector only when the LG AJ-LBX2A projector lamp has been replaced.

LGbs275_projector_lamp_reset_timer



Turn on the power.

Select MENU

Select OPTIONS/Lamp Settings

Scroll over to select Lamp Counter Reset
tare ready to reset the lamp timer.



Extend the life of the newly installed lamp with the following tips:

  • Keep your air filters clean to avoid overheating the projector.
  • Turn off the LG BS275 projector and let it stand for at least one hour ever 24 hours. An average use of four to five hours per day will ensure longer lamp life.
  • Make sure there is enough airflow around the projector particularly if it’s been permanently mounted.
  • Learn more with Top tips for extending DLP projector lamp life



Tagged with: , , ,

It’s a confusing world out there when shopping online for projector lamps. We break it down for you.

If you know what to look for then shopping for projector lamps on Amazon or ebay can land you some real deals.

Original OEM

If your projector is a newer model, then consider ordering the original OEM packaged lamp from the projector manufacturer or their authorized reseller. While this is the most expensive option as you’re paying a premium price for the brand package, plastic cage, bulb and assembling, you are guaranteed a lamp with brightness, clarity and longer lamp life. If your model is much older, you may not be getting the original branded lamp as it’s probably not in production. Look for generic lamps for your older projectors.

Third-party with original lamps

A more affordable option is to buy a replacement lamp that has an original bulb but with a third-party lamp housing. This type of lamp comes in a brown box but has the Philips, Osram, Ushio, Phoenix original bare bulb inside. This is the best value as you get a high quality branded bare bulb without paying premium prices for a branded packaging and cage.

Generic

This is the most economical choice and is mostly what you find on Amazon and other marketplaces. Generic have no OEM parts since the replacement lamp uses a generic bare bulb in a third-party housing. Picture quality, brightness and longevity won’t be the same as the OEM branded bare bulb because these non OEM manufacturers cannot use the patented technology of Philips and other manufacturers. They save you money and for many of the older projectors this is the only available option.

Avoid counterfeits

What you want to avoid are counterfeit lamps sold at an inflated price with a fake brand logo of Philips or Osram on the generic bare bulb. Sometimes even the brand packaging is counterfeited to create an authentic impression. These lamps offer NO value since they usually don’t last longer than a few hours. Sometimes they won’t fit the projector. Worse case scenario is that they explode and end up damaging the optical elements in your projector.

There are some telltale signs to watch for:

  • Often the description, even of expensive lamps, doesn’t say which bare bulb is inside: Philips, Osram, Ushio or a cheap generic Chinese bulb.
  • There may be some sort of a brand log that doesn’t link to the reseller. It’s only there to give you the impression the lamp has original parts.
  • Check that the reseller who is advertising an Osram/Philips/Ushio bare bulb inside also delivers you the original version and doesn’t substitute.

Read more on dirty little secrets about projector lamps



Sony KDS-55A2000 TVNeed to install a replacement KDS-55A2000 TV Lamp? Let this guide help.

Don’t settle for anything but the best and be sure to an authentic Sony KDS-55A2000 TV. When buying look for the seal of approval — don’t get caught with a counterfeit lamp. They have shorter lamp and are more toxic due to the substitute materials used by counterfeit manufacturers. These lamps often don’t work properly with the sensitive electronics in your projector and are prone to explosions. Keep your projector working properly and invest in an authentic projector lamp.

Warning signs

Your Sony KDS-55A2000 TV lamp should last up to 8000 hours depending in usagfe and the environment it works in. It’s time to replace the TV lamp when the screen becomes darker, or if brightness starts to diminish gradually and the colors look wrong. A message will also appear on screen asking you to replace the lamp and the LAMP LED on the front of the TV starts blinking.

Find this lamp on Amazon sold by these authorized dealers:



Replacing the lamp

Before installations preparations:

  • Unplug the AC power cord on the KDS-55A2000 TV .
  • Your Sony KDS-55A2000 uses the Sony XL-5200 Replacement TV Lamp. Before installing the lamp, let the projector cool for at least 40 minutes. It should be cool to the touch. Don’t rush the cooling as these projectors operate using extremely high temperatures and you run the risk of a serious burn.
  • _Sony KDS-60A2000 TV_Sony XL-5200 Replacement TV Lamp Take the new Sony XL-5200 lamp out of the box.Do not touch the glass portion of the new lamp. Remove the outside lamp cover.Release the two clamps as shown in the illustration below.

remove lamp door-Sony KDS-60A2000 TV_Sony KDS-60A2000 TV_Sony XL-5200 Replacement TV Lamp

  • Remove the lamp door.
  • Turn the screw counterclockwise and slide the lever to the left.
  • Remove the door.

  • Pull out the Sony XL-5200 lamp. Hold the indented grooves on the top corners of the lampand pull the lamp straight out. If the lamp is hard to remove, pull the right side of the lamp for additional traction.
  • Do not shake the lamp. Vibration can damage the lamp or shorten its life.
  • Avoid touching the front glass of a new lamp.
  • NOTE: The Sony XL-5200 TV lamp contains mercury and should not be thrown into regular garbage. Recycle this lamp!



  • Put the new Sony XL-5200 lamp into its place.
  • Insert the new lamp by pressing the two parts firmly into.
  • Make sure the lamp is securely mounted into the compartment. Failure to do so may cause a fire or the screen to go dark.



Sony KDS-60A2000 TV

  • The lamp compartment should be properly tilted (see the illustration) in order for the installation to be aligned.
  • If the lamp is not securely reattached, the self-diagnostic function may be triggered and the POWER LED blinks three times. Re-insert the lamp if this happens.

  • Reattach the lamp door.
  • Replace the door by inserting the two tabs in the slot from the left side.
  • Slide the lever to the right and then turn the screw clockwise to secure the door.
  • replace door_ new lamp_Sony KDS-60A2000 TV .pngPut the outside lamp cover back in its place.
  • Replace the cover, inserting it from the left side.
  • Press the two tabs on the right side to secure the cover.

You are now ready to reset the TV lamp timer.

Resetting the lamp timer

Turn on the Sony KDS-55A2000 TV and set the Lamp Replacement option in the Setup settings. This setting is necessary to inform you when the next lamp replacement is needed. Until you set the Lamp Replacement option, a message announcing that the lamp is at the end of its life will appear every time you turn on the TV.

reset lamp timer_replace door_ new lamp_Sony KDS-60A2000TV



    • Press MENU.
  • Select Set up. Press enter
  • Scroll down to select Clock/Timers
  • Reset the lamp timer. Press enter.
  • To exit the Settings, press MENU.
Tagged with: , ,
Join the discussion on Facebook! All your questions, answered! The Screen & Projector Group
